Perry Perry Electronic Builtin Thermostat Perry-1TITE302-MC
Perry Electronic Thermostat 1ti Te302 Mc Modulo 230v Control On/off/antigelo Led Relay Status Indication Included 3 Front Panels White Anthracite Grey On/off Fixed Differential 0.7°c Night-time Reduction Thermostat For Boiler At Best Price
UNIVERS. INC. ELECTRIC THERM. ON-OFF-ANT.
Price List
Eur. 75,75
Price MPCshop
Eur. 73,37
Available
52 Pcs Estimated Delivery in 5 working days
All prices are VAT included
Bullet points Perry Perry-1TITE302-MC
Perry 1TI TE302 MC recessed electronic thermostat MODULO series ON/OFF/ANTIGELO command Electronic thermostat forry Power supply 230V AC 50-60Hz Flush-mounted electronic thermostat with relay status indication Thermostat for boiler at the best price with Set-point with mechanical temperature lock Adjustment range 5 - 30°C
Perry 1ti Te302 Mc Recessed Electronic Thermostat Modulo Series Onoffantigelo Control Led Status Indication Relay Included 3 Front Panels White Anthracite Grey Onoff With Fixed Differential 07gradic Night Reduction 230v Ac Power Supply 5060 Hz
Customers Reviews Perry Perry-1TITE302-MC
Colla P. Data: 12 April 2020 No frills, practical, robust and easy to use, that is, I didn't have to go crazy to understand how it worked. Unbeatable price, recommended!
Vinicio Data: March 9, 2020 Works well
Electronic recessed thermostat Perry 1TITE302 MC series MODULE ON/OFF/ANTIGELO LED status indication relay included 3 frontals white anthracite grey ON/OFF with fixed differential 0,7°C Night reduction Power supply 230V c.a. 50-60Hz
Electronic Perry thermostat FEATURES
The Perry thermostat has 230V AC power supply 50-60Hz Potential-free deviation 1 contact output: 8(2)A/250V AC On/Off operation with fixed differential 0.7°C On/OFF/ANTI-FREEZE control Temperature regulation on graduated scale with mechanical set-point index Temperature levels 1 with continuous regulation Remote night-time reduction -4°C on set-point value Set-point with mechanical temperature lock LED relay status indication Regulating range 5 - 30°C Size (WxDxH) 66 x 49 x 45 mm
TECHNICAL DATA Power supply voltage: 230 V~ 50 ÷ 60 Hz Type of action, disconnection and device: 1 / B / Electronic Type of output: relay with NO/COM/NC changeover contact Potential-free, 8(2) A / 250 V~ User connections (load): 2 or 3 conductors Wire section at terminals: min. 0.75 mm2 - max. 2.5 mm2 Type of insulation: Class II Degree of protection: IP 30 Pollution degree: normal Temperature regulation range, excluding 1TITE305/MC: 5 °C to 30 °C (can be limited) Temperature regulation range, only Art. TE305/MC: from 0 °C to 60 °C (can be limited) Energy classification ErP: Class I- 1% EU Reg. 811/2013 Thermal gradient: max 1K/15 min. Differential operation: T = 0.7 °C Read accuracy: ± 1 °C Operating temperature limits: 0 °C ÷ 50 °C Reference standards for CE marking LVD EN60730-2-9 EMC EN60730-2-9
PERFORMANCE DATA Night reduction control: Removable Night reduction temperature (referred to the set): - 4 °C Antifreeze temperature (1TITE302/MC only): 5 °C fix Temperature set lock (all models): mechanical with "disk range" (supplied) Light signals (all models): Load indication LED on/off
With the three faceplates supplied in the package, the products are dimensionally and chromatically compatible with the plates of the series:
Perry Electronic Thermostat 1ti Te302 Mc Modulo 230v Control On/off/antigelo Led Relay Status Indication Included 3 Front Panels White Anthracite Grey On/off Fixed Differential 0.7°c Night-time Reduction Thermostat For Boiler At Best Price
UNIVERS. INC. ELECTRIC THERM. ON-OFF-ANT.
Price List
Eur. 75,75
Price MPCshop
Eur. 73,37
Available
52 Pcs Estimated Delivery in 5 working days
All prices are VAT included
Bullet points Perry Perry-1TITE302-MC
Perry 1TI TE302 MC recessed electronic thermostat MODULO series ON/OFF/ANTIGELO command Electronic thermostat forry Power supply 230V AC 50-60Hz Flush-mounted electronic thermostat with relay status indication Thermostat for boiler at the best price with Set-point with mechanical temperature lock Adjustment range 5 - 30°C
Data: 12 aprile 2021 Senza fronzoli, pratico, robusto e semplice nell'utilizzo, cioè non ho dovuto impazzire per capire come funzionasse. Prezzo imbattibile, consigliato!
Data: 9 marzo 2020 Funziona bene, montato un anno fa.
Termostato elettronico da incasso Perry 1TITE302 MC serie MODULO comando ON/OFF/ANTIGELO LED indicazione di stato relé inclusi 3 frontalini bianco grigio antracite ON/OFF con differenziale fisso 0,7°C Riduzione notturna Alimentazione 230V c.a. 50-60 Hz
CARATTERISTICHE del termostato elettronico Perry
Il termostato Perry ha alimentazione 230V c.a. 50-60Hz Uscita 1 contatto in deviazione libero da potenziale: 8(2)A/250Vc.a. Funzionamento ON/OFF con differenziale fisso 0.7°C Comando ON/OFF/ANTIGELO Regolazione temperatura su scala graduata con indice meccanico set-point Livelli di temperatura 1 con regolazione continua Ingresso remoto riduzione notturna -4°C sul valore di set-point Set-point con blocco meccanico temperatura LED indicazione stato relè Campo di regolazione 5 - 30°C Dimensioni (LxPxH) 66 x 49 x 45 mm
DATI TECNICI Tensione di alimentazione: 230 V~ 50 ÷ 60 Hz Tipo di azione, disconnessione e apparecchio: 1 / B / Elettronico Tipo di uscita: a relè con contatto in scambio NA/COM/NC libero da potenziale, 8(2) A / 250 V~ Collegamenti utenza (carico): 2 o 3 conduttori Sezione dei fili ai morsetti: min. 0,75 mm2 - max. 2,5 mm2 Tipo di isolamento: Classe II Grado di protezione: IP 30 Grado di inquinamento: normale Campo di regolazione della temperatura, escluso 1TITE305/MC: da +5 °C a +30 °C (limitabile) Campo di regolazione della temperatura, solo Art. TE305/MC: da 0 °C a +60 °C (limitabile) Classificazione energetica ErP: ErP: Class I- 1% Reg. EU 811/2013 Gradiente termico: max 1K/15 min. Funzionamento differenziale: T = 0,7 °C Precisione di lettura: ± 1 °C Limiti della temperatura di funzionamento: 0 °C ÷ + 50 °C Normative di riferimento per marcatura CE LVD EN60730-2-9 EMC EN60730-2-9
DATI PRESTAZIONALI Comando riduzione notturna: Remotabile Temperatura di riduzione notturna (riferita al set): - 4 °C Temperatura antigelo (solo 1TITE302/MC): +5 °C fix Blocco del set di temperatura(tutti i modelli): meccanico con "disco range" (in dotazione) Segnalazioni luminose (tutti i modelli): LED di indicazione carico inserito/disinserito
Con i tre frontalini forniti nella confezione, i prodotti risultano dimensionalmente e cromaticamente compatibili con le placche delle serie:
